OEM T6 Conservatory Aluminium Profiles For Electrical Heat Sink
OEM Aluminium Extrusion Profile For Electrical Heat Sink Aluminium
Louver Profile
Company Corporation:
Foshan Dolphin Metal Products Co., LTD is located in Foshan
Guangdong. We have been engaged in foreign trade for more than 10
years. The company has two factories in China and one in Vietnam.
We provide various high-standing T5&T6 6000 series aluminum
profile for doors&windows, conservatory, cabinet&wardrobe,
building material and etc. With professional R&D, OEM/ODM are
available. Our monthly output reaches more than 8000 Tons, so our
customers come from different countries, such as Thailand,
Malaysia, Singapore, Vietnam, Burma and etc.
Moreover, the company has a professional and responsible team to
help our customers. All processes are visualized during thr order.
Before loading, we have quality inspectors to check the products.
After the order, the aftersales staff will ask for feedback. We
have always been adhering to the concept that customers are friends
and teachers. Every feedback is a opportunity to learn and grow.
With the development of these years, Dolphin Co., LTD will be
further upgraded and expanded.
Company Advantages:
1. 20 years' experience and advanced equipment
2. Customize: We can manufacture according to your size and shape
of such aluminum profile;
3. Strong production capacity - 28 extrusion lines, 50,000TONS/Year
4. One Stop Service Specialized in mould, extrusion, anodizing,
powder coating, wood grain and Processing;
5. Shortest Delivery , competitive prices and excellent service
Introduction of Heat Sink:
The main body of the thermal insulation aluminum alloy is aluminum
material, and the plastic section cavity is used in the middle
section of the section make the heat breaking material. This
innovative structural design takes into account the advantages of
two materials, namely plastic and aluminum alloy, and meets various
requirements of decorative effect, door and window strength and
aging resistance.
The three seal structure of the doors and windows can be realized
by the insulated and broken bridge aluminum profile, the water
vapor cavity is separated reasonably, the isostatic balance of gas
and water is successfully realized, and the water tightness and
tightness of the doors and windows are greatly improved. The air
tightness of the insulated aluminum door and window is better than
any aluminum and plastic window. It can ensure the dust free in the
windowsill and floor in the area with large wind sand. It can
guarantee the residents of 50 meters on both sides of the highway
not to be disturbed by noise; and the thermal conductivity is 40 to
70% lower than that of the non insulated aluminum alloy profile and
windows
Heat Insulation Technology:
The principle of the heat insulation broken bridge aluminum alloy
is to penetrate the heat insulation strip in the middle of the
aluminum profile, and break the aluminum profile to form a broken
bridge, thus effectively preventing the heat conduction. The
thermal conductivity of insulated aluminum alloy doors and windows
is 40 to 70% less than that of non heat insulated aluminum alloy
doors and windows.
There are two main ways of producing heat insulation sections. One
is to use insulation material and aluminum profiles to form a "heat
insulation bridge" through mechanical opening, wearing and rolling.
The other is to pour heat insulation material into the heat
insulation cavity of the aluminum alloy section and remove the
broken bridge metal after curing. And other processes to form
"insulated bridge", known as "cast" heat insulation profiles. The
inside and outside sides of the thermal insulation profiles can be
profiles with different sections, or different color profiles with
different surface treatments. However, due to the geographical and
climatic effects, the gap between thermal insulation materials and
the linear expansion coefficient of aluminum profiles is very
large. In the heat expansion and contraction, there is greater
stress and gap between the two. At the same time, the heat
insulation material and the aluminum profile are combined into one.
In the windows and curtain wall structure, the same is the same as
the aluminum material. Therefore, the insulation material must also
have the tensile strength, bending strength, expansion coefficient
and modulus of elasticity that are close to the aluminum alloy
profiles, otherwise the heat insulation bridge will be broken and
destroyed. Therefore, the selection of heat insulation materials is
very important.
Specification:
| Description | Electrical Heat Sink Aluminium Louver Profile |
| Material Thickness(t) | t=1.0 / 1.1 / 1.2 / 1.4 mm |
| Materiral | Aluminum Alloy 6063, 6060. 6005, 6005A, etc |
| Annealing Treatment | T4, T5, T6, T61, T64, etc |
| Color | Champagne, Silver White ,Bronze, Grey, Black, (RAL series)etc. |
| Surface Treatment | anodized, powder coated, electrophoresis, wood grain, polished and
etc |
| Shape | Square, Round, Flat, Oval, and according to customer's drawing. |
| Length | Normal length=6m or in customer's order |
| Usage | Building, Production Line, Decoration, Industrial, Transportation,
Door and window, etc. |
| Package | 1. Pearl cotton foam for each profile; 2. Wrap with shrink film exterior; 3. Packed according to customer request. |
| Advantages/Features | Providing colorful products with various mechanical performances to adapt all kinds of architectural styles |
